MD422 Center Bore Measurement

MD422 are used for 100% process control of center bore (48-85mm) and a-value inside chaotic CNC machining cells. Trend value correction is sent to the lathe to reach center bore allowance. The Wheel is positioned for subsequent drilling with integrated optional camera system and all measured values are available for analyses. The compact design allows integration of MD422 in existing cells easily.

Your advantages

  • No mechanical wear due to contactless laser sensor
  • Valve positioning with camerasystem
  • No setup costs, just calibration in regular intervals
